Single Speed Lift Controller

JE Engineering introduces a comprehensive array of Copper Wire Harness that is manufactured by us for all types of buildings and controllers as well. A harness is prepared by collecting all the details like floor heights, overhead, length in m/c room and distance from duct, etc.

However, Copper Wire & Wire Harnesses are capable to reduces the valued wiring time and labour and ensure no scope of error in wiring connection. Our wire harness also cave wire wastages. Our outstanding wire harness is priced very economically thus we are counted amongst largest wire harness Manufacturers, Exporters and Suppliers from India.

Our offered ranges are supplied by using the best packaging materials, in order to ensure quality packaging solution. Hence, we offer our bulk quantity of harness to various countries that includes Middle East, India, Africa, U.A.E and much more. Wire harness costing will depend on floor heights and other options; it will be quoted time to time.

Features of single speed elevator controller

Simple and robust construction with telemechanic contactors.
Single PCB, hence very easy to maintain and cost effective.
State-of-art design with Low voltage and High voltage separation in PCB layout.
Ideally no extra terminals required for shaft wiring as male-female connectors are provided on PCB itself, but shaft connectors of WAGO or PHOENIX can be provided at extra cost.
Down collective
7 segment common anode display on board
LCD display to show shaft faults, car gate – landing gate – limit switches position – current position and destination of car, all pending calls, etc.
Single wire registration i.e. only one off wire from button
Counting type car top reeds – Only two reeds, one for up direction and second for down direction.
Counter for lift stopping after defined predetermined time, e.g. one day, one week, one month or two months, etc.
16 digit alphanumeric password for above counter.
On board optical isolation from field wiring.
Three stage safety chain for customer, avoiding accidental shorting of safeties by trainee technician. In no condition a technician can short entire safety of lift.
Car gate and landing gate voltage 110v
There are four limit switches – two on top floor and two on Ground floor. All limit switches are 110, for reliable intended operation. Reed switches are not allowed in place of limit switches, according to Bombay Lift rules.
All limit switches are NC according to Bombay Lift Rules.
As all components are of SMD technology, life of components increases because of reduced oxidation of contact and junctions.
Separate R-cam contactor for OTIS type locks.
As all electronics is only in one PCB, maintenance is reduced, call-back are minimised and easy to attend and diagnose the fault. Just replacing PCB solves all the problems.
Controller requires only few switchgear to complete the assembly, as all electronics is in one PCB only.
As all outputs are on the same PCB, no interconnection required between PCB’s.
DOB, Auto Fan, Auto / Manual doors relays are also available on-board.
Floor setting is field settable.
